Otterbine Fractional Series All-in-One Small Pond Aerator w/ Deluxe LED - 30M Cable | 1/2 HP

The Otterbine Fractional Aerator Deluxe LED is a versatile 1/2HP pond aerator and fountain system designed to combine effective water circulation, aeration, decorative fountain displays and LED illumination in one compact package. Ideal for small ponds, dams and water features, the Fractional Series gives property owners and professional installers multiple ways to improve water movement and presentation.

Its key advantage is the flexible 5-in-1 configuration. The unit can be configured with four interchangeable fountain patterns - Gemini, High Volume, Phoenix and Rocket - or converted into a Horizontal Mixer. This makes the system suitable for applications where decorative surface aeration, water circulation or a combination of both is required. Units are supplied in the Gemini configuration as standard.

For Australian 230V / 50Hz applications, performance varies according to the selected pattern. The Gemini configuration delivers up to 115m3/hr water flow with a spray approximately 1.2m high and 1.8m in diameter, while the High Volume pattern delivers up to 99m3/hr. Phoenix and Rocket provide taller, more concentrated displays, with the Rocket reaching approximately 3m in height.

The Deluxe package incorporates two 6.5W LED pond lights with clear lenses, producing a total lamp wattage of 13W. The lighting system operates at 12VDC and is complemented by a dedicated Mini Power Control Center with timer, transformer and photocell for convenient automatic operation.

The aerator also includes its own Mini Power Control Center with GFCI and timer, along with a debris screen to help protect the system during operation. This product variant is listed with a 30m cable, making it suitable for installations requiring additional distance between the pond system and its electrical connection point.

With multiple fountain patterns, horizontal mixing capability, LED illumination and proven Otterbine engineering, the Otterbine Fractional Aerator Deluxe LED 30m provides a flexible solution for pond aeration, circulation and decorative water displays.

Features

• 1/2HP Aerator: Compact Fractional Series system designed for small ponds and water features.
• 5-in-1 Configuration: Four interchangeable fountain patterns plus Horizontal Mixer operation.
• Four Fountain Patterns: Includes Gemini, High Volume, Phoenix and Rocket.
• Horizontal Mixer Mode: Allows the unit to be configured for horizontal water circulation.
• Gemini Standard Setup: The aerator is supplied in Gemini configuration as standard.
• High Water Circulation: Gemini configuration delivers up to 115m3/hr at 230V / 50Hz.
• Dual LED Lighting: Includes two 6.5W LED lights with clear lenses.
• 12VDC Lighting: LED system has a combined lamp output of 13W.
• Automatic Light Control: Lighting control centre incorporates a timer, transformer and photocell.
• Aerator Control Centre: Includes Mini Power Control Center with GFCI and timer.
• Debris Screen: Helps protect the aerator during pond operation.
• 30m Cable Configuration: Designed for installations requiring a longer cable run.
• Two Year Warranty: Supported by a two year manufacturer warranty.

Specifications
