PondMAX Filtration/Waterfall Pump - PU5500

The PondMAX PU5500 Filtration and Waterfall Pump is a powerful and dependable solution designed for larger koi ponds, pond filtration systems, waterfalls and continuous water circulation applications. Built with advanced soft start and anti-jam technology, the PU5500 helps prevent motor burnout during blockages, extending pump life and ensuring consistent performance.

With an impressive maximum flow rate of 5500 litres per hour and a strong 4.7 metre head height, this pump is ideal for driving pressurised filters, biological filtration systems and medium to large waterfall features. Despite its performance, the PU5500 remains energy efficient, operating at just 40 watts to help reduce ongoing power costs.

The tool-less assembly design allows for quick access and easy maintenance, making the PondMAX PU5500 suitable for both DIY pond owners and professional pond installers. Designed for Australian conditions, it offers year-round reliability and flexible hose connection options.

• Tool-Less Assembly – Enables fast and simple access for cleaning and maintenance without specialised tools
• Energy Efficient Operation – Delivers high flow performance while operating at a low 40W power consumption
• Anti-Burnout Technology – Soft start and anti-jam protection help prevent motor damage caused by blockages

• Product Code
  02PD042
• Model
  PU5500
• Max Flow (L/H)
  5500
• Max Head (M)
  4.7
• Power Consumption (W)
  40
• Voltage (V)
  220 - 240 AC
• Frequency (Hz)
  50
• IP Rating
  IPX8
• Pump Inlet BSP Thread (MM)
  25 Male
• Pump Outlet BSP Thread (MM)
  25 Male
• Stepped Hosetail Inlet (MM)
  25, 32, 38
• Stepped Hosetail Outlet (MM)
  25, 32, 38
• Recommended Tubing Size (MM)
  32
• Operating Temperature (°C)
  0 to 35
• Cable Length (M)
  10
• Dimensions (MM)
  255 x 210 x 120 (W x H x D)
• Duty Rating
  Continuous Duty (24/7)
• Warranty
  3 Years
